1/ Howo T7H 390 8x4 Benne - Howo T7H 390 8x4 Dump - Camiones Howo T7H 390 8x4 Volteo - самосвалы Китай - تفريغ الشاحنات الصين

Howo T7 H390 8x4 Benne - Howo T7H 390 8x4 Tipper - Howo T7H 390 8x4 Volquete - Sinotruk  Howo мосвалы Китай



Weight Parameter	Curb Mass(kg)		14,980
	Full Loaded Mass(kg)		31000
	Rated Towing Mass(kg)		-
Dimension Parameter	External Dimension	Length	11400
		Width	2500
		Height	3630
	Wheel Base(mm)		1950+3225+1350 1950+3200+1400
	Minimum Ground Clearance(mm)		313
Performance Parameter	Maximum Speed(km/h)		80
	Economical Speed(km/h)		50-70
	Maximum Gradeability(%)		35
	Turning Diameter(m)		21.5
Recommended Configuration	Engine	Engine Type	MC11.39-30 390 hp
		Rated Power(kw)Rev(r/min)	287/1900
		Maximum Torque(N*m)Rev(rpm)	-
	Transmission		HW19710 10 F><2R
	Clutch(mm)		Φ430
	Rear Axle	Type	AC16
		Speed Ratio	4.77 5.45
	Fuel Tank(L)		300
	Chassis Cross-section(mm)		300X80X8+280X70X8
	Suspension(Front, Back)		4/4/12 4/4/- 11/11/12 11/11/-
	Tire		11.00-20 - 11.00R20 -12.00-20 18PR - 12.00R2018PR - 315/80R22.5
