Tracteur Howo T5G 340 4X2 - Howo T5G Tractor 4X2  - Tractores Howo - Sinotruk -Part 1/2


































Engine

Model

MC07.34-30

Rated power KW/rpm

340HP

Maximum torque Nm/ rpm

1250/1200~1800

Displacement L

6.87

Type

Six cylinders inline, water cooling, 4-stroke, supercharging intermediate cooler, high pressure and common rail, EGR





Transmission

SINOTRUCK HW series 10 gears transmission, transmission with main and auxiliary transmission structure, main transmission with double countershaft, auxiliary transmission with planetary reduction.

Front axle

HF9, rated load of 9t, drum-type; heavy; load truck with HF9 drum-type, rated load of 9t.

Drive axle

MCY13Q double reduction (central reduction + hub reduction)

Suspension

Front and rear leaf spring suspension, front suspension with shock absorber, transverse stabilizer, and rear suspension is disconnected type with transverse stabilizer.

Steering system

ZF8098 steering gear, ZF steering oil pump, system pressure 18MPa

Braking system





Service brake: dual-circuit air pressure brake; parking brake; spring storage energy without air; auxiliary brake: engine exhaust braking; standard engine EVB, with ABS and optional auto clearance adjusting arm.

Tire

12.00-20

Tank volume L

400

Gross mass  kg

25000

Authorized maximum towed mass  kg

39000

Complete vehicle external dimensions ( length*width*height) mm

6725*2496*3800
