Semi Remorques Bennes Export 20 > 35 m3 - Tipper Semi Trailers China 20 >35 m3 - Volquete Semirremolque China 20 >35 m3



semi emorques plateau , semi remorques porte conteneurs , semi remorques porte engins ,semi remorque squelette ,semi remorque savoyarde ,semi remorque porte engins, semi remorque fourgon ,semi remorque benne

Semi bennes K



Semi remorque benne R



Semi remorque benne P



Semi remorque benne Q



  Semi remorque benne T



Semi remorque benne U



Semi remorque benne V



Semi remorque benne W



Semi bennes G



Semi remorque benne VB



Semi remorques bennes M



Tare  Weight 11000kg
Payload 35000kg
Total  Weight 46000kg
Overall  Length 9900mm
Overall  Width 2465mm
Overall  Height 3726mm
Wheel Track 1840mm
Wheel base 4250mm+1300mm+1300mm
Volume 24 cbm
External dimension (L x W x H): 9680mmx2465mmx2240mm
Inner dimensions (L x W x H):

8720mmx2300mmx1200mm
Floor 8mm thickness
Side Wall 6mm thickness
Front Wall 8mm thickness
Hydraulic system HYVA  FC191-5-06180 cylinder
Axle BPW /  FUWA
Suspension  FUWA style mechanical 3-axle suspension
Leaf Spring FUWA
King Pin 1
Landing Gear JOST-C200
Tire 13 units /11R22.5
Twist Lock 8 sets
 Wheel Carrier 1
Braking System WABCO
